Miller Multimatic 235 Multi-Process Welder – Running Gear

The Miller Multimatic 235 (951846) is a MIG, flux-cored, stick and DC TIG welder on 120/240V with MVP plug and 30-235A, welding up to 1/2-inch steel (60% at 170A on 240V). It has a color LCD with Auto-Set Elite, 60-600 IPM feed and includes running gear; TIG kit optional. About 63 lb.

Specifications

• Brand: Miller
• Part / Model Number: 951846
• Processes: MIG (GMAW), Flux-Cored (FCAW), Stick (SMAW), DC TIG (GTAW)
• Input Voltage: 120V / 240V (MVP Plug)
• Output Range: 30 – 235 Amps
• Weld Thickness Capacity: Up to 1/2 inch mild steel
• Duty Cycle: 60% @ 170A (240V), 40% @ 115A (120V)
• Wire Feed Speed: 60 – 600 IPM
• Display: Color LCD with Auto-Set Elite
• Running Gear: Included (with cylinder rack)
• TIG Capable: Yes (requires optional TIG kit)
• Dimensions: 29.5 in L × 11.25 in W × 23.75 in H
• Weight: Approx. 63 lbs (unit only)
• GTIN: 715959674848

Brand: Miller

Model: Multimatic 235 with Running Gear

MPN: 951846

Processes: MIG (GMAW), Flux-Cored (FCAW), Stick (SMAW), DC TIG (GTAW)

Input Voltage: 120V / 240V (MVP Plug)

Output Range: 30 – 235 Amps

Weld Thickness Capacity: Up to 1/2 inch mild steel

Duty Cycle: 60% @ 170A (240V), 40% @ 115A (120V)

Wire Feed Speed: 60 – 600 IPM

Display: Color LCD with Auto-Set Elite

Running Gear: Included (with cylinder rack)

Spool Gun Ready: Yes (Spoolmate 200 compatible)

TIG Capable: Yes (requires optional TIG kit)

Dimensions: 29.5 in L × 11.25 in W × 23.75 in H

Weight: Approx. 63 lbs (unit only)

GTIN: 715959674848

Google Product Category: 2920 (Welding Machines)

Warranty: 3-Year Miller True Blue Warranty

Part Number: 951846
