Miller Dynasty 800 907719 High-Output AC/DC TIG/Stick Welder
The Miller Dynasty 800 (907719) is an inverter AC/DC TIG and stick welder on 208-575V 3-phase with Auto-Line and 5-800A (100% at 800A on 480V). It has four AC waveforms, 60-90% EN balance, 20-400 Hz frequency, independent EP/EN amperage and program memory; 185 lb.
CONTROL FOR EVERY BEAD
PRECISION WHERE
THE WORK DEMANDS IT
The Miller Dynasty 800 (907719) is an inverter AC/DC TIG and stick welder on 208-575V 3-phase with Auto-Line and 5-800A (100% at 800A on 480V). It has four AC waveforms, 60-90% EN balance, 20-400 Hz frequency, independent EP/EN amperage and program memory; 185 lb.
- Brand: Miller
- Model: Dynasty 800
- MPN: 907719
- Processes: TIG (GTAW), Stick (SMAW)
- Input Voltage: 208–575 V, 3-Phase, Auto-Line
Dependablepower →
COMPLETE PRODUCT INFORMATION
Full Product Description
The Miller Dynasty 800 (907719) is an inverter AC/DC TIG and stick welder on 208-575V 3-phase with Auto-Line and 5-800A (100% at 800A on 480V). It has four AC waveforms, 60-90% EN balance, 20-400 Hz frequency, independent EP/EN amperage and program memory; 185 lb.
Specifications
- Brand: Miller
- Part / Model Number: 907719
- Processes: TIG (GTAW), Stick (SMAW)
- Input Voltage: 208–575 V, 3-Phase, Auto-Line
- Output Range: 5 – 800 Amps
- Duty Cycle: 100% @ 800A (480V)
- AC Waveforms: Advanced Squarewave, Soft Squarewave, Sinewave, Triangular
- AC Balance Control: Adjustable 60–90% EN
- AC Frequency Control: 20–400 Hz
- Independent Amperage Control: Yes (EP and EN independently adjustable)
- Memory Settings: Yes, with program storage
- Dimensions: 17 in H x 14.25 in W x 28 in D (432 mm x 362 mm x 711 mm)
- Net Weight: 185 lb (83.9 kg)
- Power Source Type: Inverter
- Applications: Heavy Fabrication, Aerospace, Pipe Welding, Shipbuilding, Manufacturing
- Weldable Materials: Aluminum, Stainless Steel, Carbon Steel, Titanium
Technical Specifications
Product data| Product | Miller Dynasty 800 907719 High-Output AC/DC TIG/Stick Welder |
|---|---|
| SKU | 907719 |
| Brand | Miller |
| Model | Dynasty 800 |
| MPN | 907719 |
| Processes | TIG (GTAW), Stick (SMAW) |
| Input Voltage | 208–575 V, 3-Phase, Auto-Line |
| Output Range | 5 – 800 Amps |
| Duty Cycle | 100% @ 800A (480V) |
| AC Waveforms | Advanced Squarewave, Soft Squarewave, Sinewave, Triangular |
| AC Balance Control | Adjustable 60–90% EN |
| AC Frequency Control | 20–400 Hz |
| Independent Amperage Control | Yes (EP and EN independently adjustable) |
| Memory Settings | Yes, with program storage |
| Dimensions | 17 in H x 14.25 in W x 28 in D (432 mm x 362 mm x 711 mm) |
| Net Weight | 185 lb (83.9 kg) |
| Power Source Type | Inverter |
| Technology | Auto-Line, Fan-On-Demand, Cooler Power Supply (CPS) Compatible |
| Applications | Heavy Fabrication, Aerospace, Pipe Welding, Shipbuilding, Manufacturing |
| Weldable Materials | Aluminum, Stainless Steel, Carbon Steel, Titanium |
| Warranty | 3-Year Miller True Blue Warranty |
| Condition | New |
| Part Number | 907719 |
Engineered forreal-world performance907719
DELIVERY & AFTER-SALES INFORMATION
Shipping & Returns
Important information for this product before and after purchase.Heavy or oversized equipment delivery is coordinated according to the product and destination address.
Timing and applicable delivery arrangements are confirmed during checkout or by Kayros Tool support.
Contact Kayros Tool before returning an item so eligibility, product condition, and return instructions can be confirmed.
Overview
The Miller Dynasty 800 (907719) is an inverter AC/DC TIG and stick welder on 208-575V 3-phase with Auto-Line and 5-800A (100% at 800A on 480V). It has four AC waveforms, 60-90% EN balance, 20-400 Hz frequency, independent EP/EN amperage and program memory; 185 lb.
Specifications
- Brand: Miller
- Part / Model Number: 907719
- Processes: TIG (GTAW), Stick (SMAW)
- Input Voltage: 208–575 V, 3-Phase, Auto-Line
- Output Range: 5 – 800 Amps
- Duty Cycle: 100% @ 800A (480V)
- AC Waveforms: Advanced Squarewave, Soft Squarewave, Sinewave, Triangular
- AC Balance Control: Adjustable 60–90% EN
- AC Frequency Control: 20–400 Hz
- Independent Amperage Control: Yes (EP and EN independently adjustable)
- Memory Settings: Yes, with program storage
- Dimensions: 17 in H x 14.25 in W x 28 in D (432 mm x 362 mm x 711 mm)
- Net Weight: 185 lb (83.9 kg)
- Power Source Type: Inverter
- Applications: Heavy Fabrication, Aerospace, Pipe Welding, Shipbuilding, Manufacturing
- Weldable Materials: Aluminum, Stainless Steel, Carbon Steel, Titanium
Specifications
Brand: Miller
Model: Dynasty 800
MPN: 907719
Processes: TIG (GTAW), Stick (SMAW)
Input Voltage: 208–575 V, 3-Phase, Auto-Line
Output Range: 5 – 800 Amps
Duty Cycle: 100% @ 800A (480V)
AC Waveforms: Advanced Squarewave, Soft Squarewave, Sinewave, Triangular
AC Balance Control: Adjustable 60–90% EN
AC Frequency Control: 20–400 Hz
Independent Amperage Control: Yes (EP and EN independently adjustable)
Memory Settings: Yes, with program storage
Dimensions: 17 in H x 14.25 in W x 28 in D (432 mm x 362 mm x 711 mm)
Net Weight: 185 lb (83.9 kg)
Power Source Type: Inverter
Technology: Auto-Line, Fan-On-Demand, Cooler Power Supply (CPS) Compatible
Applications: Heavy Fabrication, Aerospace, Pipe Welding, Shipbuilding, Manufacturing
Weldable Materials: Aluminum, Stainless Steel, Carbon Steel, Titanium
Warranty: 3-Year Miller True Blue Warranty
Condition: New
Part Number: 907719
