BluePrint Engines Marine Pro Series PSM6320CTC1 GM 632 Dressed Long Block – 775 HP

The BluePrint PSM6320CTC1 is a Marine Pro Series GM 632 (10.3L) big block dressed long block rated 775 HP, with aluminum heads, cast iron block, hydraulic roller cam and internal balance. Includes carburetor, heads, distributor, balancer, intake, oil pan, plug wires, plugs, timing cover and valve covers; air cleaner, computer, flexplate, flywheel, supercharger, throttle body, water pump and harness are not included.

Specifications

• Brand: BluePrint Engines
• Part / Model Number: PSM6320CTC1
• Actual Engine Displacement: 10.3L/632
• Assembled: Yes
• Cam Style: Hydraulic roller
• Crate Engine Cylinder Head Material: Aluminum
• Crate Engine Family: Chevy Big Block
• Engine Balance: Internal
• Engine Block Material: Cast iron
• Intake Manifold Style: Carbureted
• Part Type: Crate Engines
• Rear Main Seal Style: 1-piece
• Remanufactured: No

Included: Carburetor, Cylinder Heads, Distributor, Harmonic Balancer, Intake Manifold, Oil Pan, Spark Plug Wires, Spark Plugs, Timing Cover, Valve Covers.

Actual Engine Displacement: 10.3L/632

Air Cleaner Included: No

Assembled: Yes

Brand: BluePrint Engines

Cam Style: Hydraulic roller, OE roller

Carburetor Included: Yes

Computer Included: No

Crate Engine Cylinder Head Material: Aluminum

Crate Engine Family: Chevy Big Block

Cylinder Heads Included: Yes

Distributor Included: Yes

Engine Balance: Internal

Engine Block Material: Cast iron

Flexplate Included: No

Flywheel Included: No

Harmonic Balancer Included: Yes

Intake Manifold Included: Yes

Intake Manifold Style: Carbureted

Manufacturer's Part Number: PSM6320CTC1

Notes: For boats being used in salt water, BluePrint Engines recommends a closed cooling system be used as the aluminum cylinder heads and intake manifolds do not have brass lined water passages. Tall deck engine. Block has a mechanical fuel pump provision. Requires an internal balance flywheel/flexplate. The 1-piece rear main seal small block Chevy flywheel/ flexplate will not bolt to this engine. O balance flywheel or flexplate must be used. See the suggested parts tab for the correct flywheel or flexplate to use with this engine.

Oil Pan Included: Yes

Part Type: Crate Engines

Product Line: BluePrint Engines Marine Pro Series GM 632 C.I.D. 775 HP Dressed Long Block Crate Engines

Quantity: Sold individually.

Rear Main Seal Style: 1-piece

Remanufactured: No

Spark Plug Wires Included: Yes

Spark Plugs Included: Yes

Supercharger Included: No

Throttle Body Included: No

Timing Cover Included: Yes

UPC: 00887753744791

Valve Covers Included: Yes

Water Pump Included: No

Wiring Harness Included: No
